PORT DESIGNS DOCKING TYPE C TRAVEL 1 X 4K ++ NS
You have to log in to shop/see prices.
|
|
PORT DESIGNS DOCKING TYPE C TRAVEL 1 X 4K ++ NS
-
Ports
4
-
Display Ports
0
-
HDMI Ports
1
-
Network
1
|
Description
Specifications
Port Designs 901906. Host interface: USB 3.0 (3.1 Gen 1) Type-C, Hub interfaces: HDMI,RJ-45,USB 3.2 Gen 1 (3.1 Gen 1) Type-A,USB 3.0 (3.1 Gen 1) Type-C,VGA,mini DisplayPort, Maximum resolution (HDMI): 3840 x 2160 pixels. Data transfer rate: 5000 Mbit/s, Product colour: Black, Housing material: Aluminium. Ethernet interface type: Gigabit Ethernet. Power source type: USB, Power consumption (typical): 60 W, Output voltage: 20 V. Windows operating systems supported: Windows 10
| Ports quantity | 9 |
| Host interface | USB 3.0 (3.1 Gen 1) Type-C |
| Hub interfaces | HDMI,RJ-45,USB 3.2 Gen 1 (3.1 Gen 1) Type-A,USB 3.0 (3.1 Gen 1) Type-C,VGA,mini DisplayPort |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| HDMI ports quantity | 1 |
| Maximum resolution (HDMI) | 3840 x 2160 pixels |
| VGA (D-Sub) input ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Card reader integrated | Yes |
| Card reader slot | 2 |
| Compatible memory cards | MMC,MicroSD (TransFlash),SD |
| Data transfer rate | 5000 Mbit/s |
| Product colour | Black |
| Housing material | Aluminium |
| Hot-swap | Yes |
| Cable length | 0.25 m |
| Plug and Play | Yes |
| Country of origin | China |
| Certification | CE, RoHS |
| Ethernet interface type | Gigabit Ethernet |
| Power source type | USB |
| Power consumption (typical) | 60 W |
| Output voltage | 20 V |
| Output current | 3 A |
| USB charging port | Yes |
| USB powered | Yes |
| Windows operating systems supported | Windows 10 |
| Mac operating systems supported | Yes |
| Width | 137 mm |
| Depth | 75 mm |
| Height | 17 mm |
| Weight | 204 g |
| Package width | 142 mm |
| Package depth | 208 mm |
| Package height | 30 mm |
| Package weight | 264 g |
| Manual | Yes |
| Cable colour | Black |
| Pallet width | 34 cm |
| Pallet length | 36 cm |
| Pallet height | 24.5 cm |
| Quantity per pallet | 1000 pc(s) |
| Shipping (inner) case width | 16 cm |
| Shipping (inner) case length | 34 cm |
| Shipping (inner) case height | 23.5 cm |
| Shipping (inner) case net weight | 3.73 kg |
| Number of cartons per pallet layer | 10 |
| Number of layers per pallet | 5 |
