KENSINGTON n UH1440P - Docking station - USB-C 3.2 Gen 1 / Thunderbolt 3 / Thunderbolt 4 - DP, HDMI, VGA - 1GbE
-
Ports
4
-
USB-A Ports
3
-
USB-C Ports
1
-
Display Ports
1
-
HDMI Ports
1
-
Network
1
-
Card Reader
True
-
Host Interface
USB Type-C
|
Description
Specifications
Professionals find that they can be more productive when connected to multiple monitors. With more people working between different locations and connecting to different (and often legacy) monitors, a compact, mobile dock that can accommodate these setups is required. The UH1440P USB-C Mobile Dock makes the most of legacy monitors, allowing you to connect up to two DP/HDMI or DP/VGA monitors. Universally compatible, this USB-C driverless dock supports up to 85W power pass-through - ideal if you don’t wish to travel with a bulky power brick. Instead, you can use your laptop’s USB-C power supply to charge your laptop while also powering the dock. The 10-in-1 design includes three USB-A ports, a 3.5mm audio jack, Micro and SD card slots and one Gigabit Ethernet port.
| Connectivity technology | Wired |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery revision | 3.0 |
| USB Power Delivery up to | 85 W |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| VGA (D-Sub) ports quantity | 1 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.2 |
| Combo headphone/mic port | Yes |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
| HDCP | Yes |
| HDCP version | 1.4 |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,1000 Mbit/s |
| Product colour | Silver |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), SD |
| Data transfer rate | 5 Gbit/s |
| HD type | 4K Ultra HD |
| Maximum digital resolution | 3840 x 2160 pixels |
| Maximum analog resolution | 1920 x 1080 pixels |
| Number of displays supported | 2 |
| Maximum refresh rate | 60 Hz |
| Plug and Play | Yes |
| Housing material | Aluminium |
| Country of origin | China, Vietnam |
| Power source type | USB |
| USB cable length | 0.17 m |
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Mobile operating systems supported | iPadOS |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Width | 137 mm |
| Depth | 75 mm |
| Height | 17 mm |
| Weight | 200 g |
| Quantity per pack | 1 pc(s) |
| Package width | 124 mm |
| Package depth | 183 mm |
| Package height | 27 mm |
| Package weight | 110 g |
| Quick start guide | Yes |
| Compliance certificates | CB, CE, Federal Communications Commission (FCC), RCM, RoHS, UKCA, VCCI |
| Products per master (outer) case | 10 pc(s) |
| Master (outer) case width | 140 mm |
| Master (outer) case length | 376 mm |
| Master (outer) case height | 130 mm |
| Master (outer) case gross weight | 2.44 kg |
| Master (outer) case net weight | 1.69 kg |
| Compatible operating systems | macOS 10.15 or above; Windows 10 or above |
| USB ports quantity | 3 |
